Name: [Bending] Radial Feeder GS-RDD2105(L)
Brand: Global Soul Limited
SKU: GS-RDD2105(L)
Availability: InStock

家へ > 製品 > SMTフィーダー >

[Bending] Radial Feeder GS-RDD2105(L)

Place of Origin:

China

ブランド名:

Model Number:

GS-RDD2105(L)

連絡ください

引金を求めてください

製品の詳細

Feeder type:

GS-RDD2105（L）

explain:

Feeder reference material dimensions(mm)

Material width:

≤14

Material length:

≤14

Material height:

≤30

Pin spacing 1:

Standard knife：≤10(Default standard knife)

Pin spacing 2:

Wide knife：8-13(Optional)

Pin spacing 3:

Big knife：8-23(Optional)

Pin diameter:

The largest1.0

Hole spacing:

12.7or15(Default12.7)

Adjustable range of the cutting knife:

0-6(Based onW+2)

The distance from the main body to the bending point:

≥1.5

Braided tape height:

The minimum position dimension of the foot cutter:

2(The minimum residual exposed size after the pins are cut)

支払いおよび配送条件

Minimum Order Quantity

1 PCS

価格

USD+negotiable+pcs

Packaging Details

850*85*170mm

Delivery Time

1-7 days

Payment Terms

T/T

Supply Ability

1+pcs+per days

[Bending] Radial Feeder GS-RDD2105(L)

最高の価格を入手する

[Hook Type] Radial Feeder (GS-RDD2112)

最高の価格を入手する

Surface Mount Ic Tube Mounting (GS-SHQ2304)[Dual Track]

最高の価格を入手する

Surface Mount IC Tube Mounting (GS-SAQ2306)

最高の価格を入手する

連絡ください

86-0755-27678283

今連絡してください

製品説明

[BENDING] VERTICAL FEEDER GS-RDD2105(L)

The Vertical feeder is an electronic component supply device that keeps a certain interval and sends out the electronic components of the Vertical tape packaging one by one at a specified time, cuts the lead wires, and supplies them to the insertion machine.

[Bending] Radial Feeder GS-RDD2105(L) 0

[Bending] Radial Feeder GS-RDD2105(L) 1

[Bending] Radial Feeder GS-RDD2105(L) 2

Display at the bend

[Bending] Radial Feeder GS-RDD2105(L) 3

[Bending] Radial Feeder GS-RDD2105(L) 4

Specifications and Parameters

[Bending] Radial Feeder GS-RDD2105(L) 5

[Bending] Radial Feeder GS-RDD2105(L) 6

Radial feeder is suitable for the specifications of braided materials

[Bending] Radial Feeder GS-RDD2105(L) 7

If there are special material dimensions, you can contact our company for consultation and to provide solutions and customize exclusive feeders.
